Redundant 1024 Points SOE System with Panel

Redundant 1024 Points SOE System with Panel

Customer Requirement

  • 1000 points sequence of event recorder for cogen CPP (365 MW)

Systems and Tools

  • Redundant event logger with 1000 points system
  • Configuration & historical events software
  • Fully wired panel

Project Scope

  • A standalone sequence of event recording system (SERS) with a dedicated laserjet printer and PC with TFT monitor shall be provided
  • SER shall accept sequence of event (SOE) inputs in the form of potential free contacts (closures/openings)
  • Each contact will be diode auctioneered and dual shared between sequence of events recording system & digital control system
  • The number of SOE inputs shall be as decided during detailed engineering but not less than 1000 points
  • The SERS shall be synchronized with Master Clock System, every minute using IRIG-B signal
  • The accuracy of the clock on the processors/controllers or input modules as well as the internal synchronization rate shall be adequate to meet the resolution requirements
